Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve
Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve
Product Details
Place of Origin: Jianshan city, Zhejiang Province, China
Brand Name: BOYO INTERIOR MATERIALS
Certificate: CE/ISO
Model No.: BY-JF23100
Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve
Payment & Shipping Terms
Minimum Order Quantity: Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve
Valve 100PCS
Price: Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve According to The Final Quantity and Cost
Package: P Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve 3 Corrugated Paper Boxes with Pallets for LCL, FCL without Pallets
Delivery Time: Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve 7-15 Days
Payment term: Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve L/C at Sight, T/T, D/P at Sight
Price Term: FOB SHANGHAI /NINGBO Port, CNF/CIF Destination Port
Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve
Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve Description
Model No.: BY-JF23100 Materials: Brass/Alloy
Inlet Thread: PZ25.4 Handle: Metal/Stainless Steel
Type: Carbon Dioxide Fire Extinguisher Brass Valve , Trolley extinguisher valve,Brass valve
Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve Advantages
1) The fire extinguishing valve shown is suitable for carbon dioxide fire extinguishers.
2) Easy to operate and beautiful appearance.
3) Pressure gauges, hoses and siphons can be connected as required.
4) With high quality, competitive price and professional service.
5) Pass ISO and CE certification
Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve Technology Data
ITEM | SPECIFICATION |
Article Code | JF-23100 |
INLET THREAD | PZ25.4 |
OUTLET THREAD | M22*1.5 |
GAUGE CONNECTION THREAD | M10*1 |
SAFELY RELIEVE PRESSURE | 18-22 |
WALL HANGING LOOP | NO |
What are the types of Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve?
1. Fuse type carbon dioxide fire extinguisher valve structure
The fuse-type valve has a simple structure, and there is a fuse locking valve button in the center of the structure. The disadvantage of fuse-type valve is that they cannot be reused and the entire valve must be replaced.
2. Diaphragm carbon dioxide fire extinguisher valve structure
There is a diaphragm in the center of the diaphragm valve structure. When the internal pressure of the cylinder reaches a certain value, the diaphragm will be pushed up by the gas, thus activating the diaphragm and causing carbon dioxide to flow out of the valve. When the pressure inside the cylinder drops, the valve automatically closes. Diaphragm valves can be reused, but because the material is prone to aging, they need to be replaced regularly.
3. Valve structure of piston carbon dioxide fire extinguisher
There is a piston and spring in the center of the piston valve structure. When the internal pressure of the cylinder reaches a certain value, the spring is compressed and the piston starts, allowing carbon dioxide to flow out of the valve. When the pressure inside the cylinder drops, the spring presses the piston back and the valve automatically closes. Piston valves can be reused, but their structures are more complex.
What is the importance of Trolley CO2 Carbon Dioxide Fire Extinguisher Brass Valve?
The fire extinguisher valve plays a key role in fire extinguishing. It can ensure the balance of air pressure inside the fire extinguisher and the accurate adjustment of the nozzle injection speed and direction, so that the fire extinguishing agent can be sprayed out with the best effect and effectively control the fire.
At the same time, during the daily use of fire extinguishers, we also need to pay attention to the status of the valve, ensure that the valve is in intact condition, and strengthen daily maintenance.
